PRODUCT DETAILS
| Model | CSD15 | ||||||||||
| Type of power | Lead-acid battery | ||||||||||
| Driving type | Seated-on type | ||||||||||
| Rated load | Q(kg) | 1500 | |||||||||
| Liting height | h3(mm) | 9000 | |||||||||
| Overall length | L1(mm) | 3030 | |||||||||
| Overall width | b1/b2 | 1575 | |||||||||
| Fork dimensions | s/e/l(mm) | 45/125/1200 | |||||||||
| Outside width of forks | b5(mm) | 760 | |||||||||
| Mast closed height | h1(mm) | 4310 | |||||||||
| Free lifting height | h2(mm) | 3115 | |||||||||
| Max height of mast during lifting(including load backrest) | h4(mm) | 10160 | |||||||||
| Height of overhead guard | h6(mm) | 2190 | |||||||||
| Height of station board | h7(mm) | 316 | |||||||||
| Min height of mast off the ground | mm | 50 | |||||||||
| Height of vehicle off the ground | m(mm) | 40 | |||||||||
| Battery,voltage/capacity | V/Ah | 48/420 | |||||||||
| Weight of battery | kg | 665 | |||||||||
| Vehicle weight (including battery) | kg | 7300 | |||||||||
| Driving motor Power(S2-60MIN) | kw | 6.5(AC) | |||||||||
| Liting motor power | kw | 8.6(DC) | |||||||||
| Tire | Polyurethane | ||||||||||
| Tire dimensions,drive wheel | mm | φ400x140 | |||||||||
| Tire dimensions,bear wheel | mm | φ140x127 | |||||||||
| Dimension of balance wheel | mm | φ100×50 | |||||||||
| Number of wheels,front/rear(x=drive wheel) | 4/1X-2 | ||||||||||
| Wheel track,drive side | mm | 960 | |||||||||
| Wheel track,bear side | mm | 1323 | |||||||||
| Wheelbase | y(mm) | 1700 | |||||||||
| Load center | C(mm) | 600 | |||||||||
| Front overhang | x(mm) | 675 | |||||||||
| Turn radius | Wa(mm) | 1990 | |||||||||
| Stacking channel width (1t pallet 1000×1000)(1.5 t pallet 1200x1200) | Ast1(mm) | 1620 | |||||||||
| Minimum main channel(1t pallet 1000x1000)(1.5t pallet 1200×1200) | Ast2(mm) | 3675 | |||||||||
| Full load axle load,drive side/bear side | kg | 2700/6100 | |||||||||
| No-load axle load,drive side/bear side | kg | 3350/3950 | |||||||||
| Driving speed,full load/no load | km/h | 7.8/8 | |||||||||
| Lifting speed,full load/no load | mm/s | 140/300 | |||||||||
| Descent speed,full load/no load | mm/s | 300/160 | |||||||||
| Braking type | Electromagnetic brake | ||||||||||
| Steering type | Electronic steering | ||||||||||
| Battery replacement method | Side pull type | ||||||||||
